Fixed Type 1.3S Automatic Bundle Cable Tie Machine
Small fast 1.3S Automatic bundle cable tie machine with 4,000pcs reel zip ties
To optimize the process of using nylon cable ties!
To save cost and time!
Scope of applications of automatic cable tie machine
Be suitable for big copper tubes with insulation cotton in air conditioning.
Or something bigger(diameters from 31mm to 42mm)
Working process of automatic cable tie machine
Working principle: The material distribution mechanism separates cable ties one by one. After the sensor detects the cable ties, they would be transported to the feeding tube. When the operator steps on the pedal, the cable tie is transported to the cable tie gun head, and pulled, tightened and cut. At last the waste materials can be collected into the waste box.
Operation process: load reel cable ties – Click “Load” only one time – Click “Start” – Place the bundled objects – tread the foot pedal – finish packing/bundling.
Basic use of automatic cable tie gun
1. Applicant cable ties: C36200, REEL cable ties, Width 3.6 * Length 200mm.
2. Applicant products: ask to bundle tightly through cable ties.
3. Industry: wire harness, household appliance.
4. Case: copper tubes in air conditioning
Technical data of automatic nylon cable tie machine
| Item | Data |
| Automatic cable tie machine model | SWT36200FC |
| Bundle speed | 1.3S per cable tie |
| Bundle productivity | 2,000pcs - 3,000pcs/h |
| Applicable cable ties model | C36200(reel nylon zip ties) |
| Applicable length/width/thickness of cable ties: | 200mm/3.6mm/1.2mm |
| Applicable wire harness/tubes diameters | Ø15mm – ø42mm for wire harness; Ø15mm – ø40mm for tubes |
| Voltage | AC220, 50/60Hz |
| Power | 1,000W |
| Pneumatic pressure | 5kg/cm² |
| Host size/weight | L510 * W480 * H230mm |
| Fixed cable tie gun size | L299*W270*T149mm |
| Fixed cable tie gun weight | 4.2kg/pcs |
Features/functions of automatic cable tie system
1. There are 4,000pcs nylon cable ties per reel. So operator doesn’t have to load materials often.
2. The cable tie machine is small. Its weight is about 30kg. It is easy to move.
3. PLC control system and touch screen. Easy to manage the parameters.
4. Once tread the pedal, cable ties would be automatically wrapped, tightened and cut.
5. The bundle speed is 1.3S single cable tie.
6. The waste would be collected into a box.
7. The binding forces are adjustable.
8. Voltage: AC220V, 50/60Hz; pneumatic pressure: 5kg/cm²
About packing
Machine would be packed in wooden case.
Cable ties in reels would be packed in carton boxes.
About delivery
1. Lead time for machine: 7workig days
2. Lead time for cable ties in reel: 10days.
3. Could be shipped by air, ups etc.
4. 1 year warranty and tech support forever
FAQ
Q1: Do you have machines that can bundle object diameter up to 50mm?
A1: No, 42mm is the max diameter. There isn’t a machine can bundle such a big item.
Q2: Must the machine SWT36200FC use reel cable ties?
A2: Yes, it uses reel cable ties C36200, width 3.6mm * length200mm.
